Digital Multimeter

Specification

  • Square wave output
  • Data Hold
  • polarity Indication
  • Over range Indication
  • Over load protection
  • Automatic- Power Off 15 min



Where To Buy
Category:

Description

ITEM CODEMS-DM1907
DISPLAY31/2 digit LCD, with a max. reading of 1999
NEGATIVE POLARITY INDICATIONNegative sign “-” shown on the display automatically
SAMPLING RATEAbout 2 to 3 times/sec
OPERATING ENVIRONMENTTemperature: 0°C to 40°C
RELATIVE HUMIDITY< 75%
TEMPERATURE COEFFICIENT0.2 x (specified accuracy)/°C(< 18°C or > 28°C)
STORAGE ENVIRONMENTTemperature: -10°C to 50°C
RELATIVE HUMIDITY< 85%RH
OPERATING ALTITUDE0 to 2000 meters
IP DEGREEIP20
BATTERYVbattery, 6F22 or equivalent, 1 piece
LOW BATTERY INDICATION“ “ shown on the display
SIZE144x80x38mm
QTY / BOX (INNER / MASTER)1 / 36

About 214g (including battery)

WEIGHT (gr)
